Suzuki DF40A-DF250A 4-Inch Troll Mode Tachometer (White) 34200-93J54

Suzuki DF40A-DF250A 4-Inch Troll Mode Tachometer (White) 34200-93J54 is an easy-to-read analog tachometer designed around Suzuki's Troll Mode System. It combines a normal 0-7,000 RPM scale with a secondary 0-3,000 RPM scale marked in 50 RPM intervals to make low-speed trolling adjustments easier.

Compatible Applications

• For compatible Suzuki DF40A through DF250A mechanical-control applications where this troll-mode analog tachometer is specified.

Specifications

• Suzuki Part Number: 34200-93J54
• Product Type: 4-inch tachometer with Suzuki Troll Mode scale
• Color: White
• Primary Scale: 0-7,000 RPM
• Secondary Troll Scale: 0-3,000 RPM with 50 RPM markers
• Warning Lamps: Engine temperature, low oil, check engine and over-rev

Supersedes / Replaces

• Supersedes / Replaces: 34200-93J53

Application / Installation Notes

• When Troll Mode is engaged, the over-rev lamp remains illuminated as the Troll Mode indicator.
• Verify the engine's instrumentation system before ordering; digital/AP configurations may require digital instrumentation instead.

Important Compatibility Information: Suzuki parts can vary by engine model, serial number, and production date. Application information is provided as a general reference. Always verify compatibility using your engine serial number before ordering.

To Confirm Compatibility: Contact our team with your engine serial number at (727) 596-5929 before ordering.
